Volume: 46.25x26.6x14.2mm (LxWxH)
Weight: 12.1g
Channel count: 8ch (PWM)/16ch (SBUS)
RSSI (Signal Strength Indicator) output: PWM
Working voltage range: 4.0~10V
Operating current range: 100mA@5V
Effective distance: Full distance (>1.5km)
compatibility:
In D8 mode: FrSky Taranis X9D/XJT/DFT/DJT/DHT/DHT-U
In D16 mode: FrSky Taranis X9D/XJT
Size: 46.25x26.6x14.2 millimeters (length x width x height) Weight: 12.1g
Number of channels: 16CH (18 channels output from traditional channels, 116 channels output from system bus ports or merge two X8Rs into one 16 channel receiver)
With RSSI output: analog voltage output (03.3V)
Working voltage range: 4.010V
Working current: 100mA@5V
Receiving range:>1.8 kilometers
Compatibility of firmware upgrade: RuiSiKai DFT/DJT/DHT/DHT-U
Frsky X9D/XJT D8 mode
Frsky X9D/XJTD16 mode
The coding process
Code pairing is the process of associating a receiver with a specific transmitter module. A transmitter module can be bound to multiple receivers (cannot be used simultaneously), and a receiver can only be bound to one transmitter module.
Follow the steps below to complete the code:
1. Turn on the control, press and hold the F/S button on the module (please refer to the module manual for the switch position) and turn on the power. Release the F/S button, and the red light on the XJT module will flash, indicating that the control has entered the code pairing state;
2. Press and hold the F/S button on the X8R receiver and turn on the power. The red light on the receiver flashes, indicating successful surface pairing;
3. Close control and receive
4. Open the control and connect the battery to the receiver. The green light on X8R indicates normal operation. Re coding is only required when either the receiver or module is replaced.
Attention: After completing the coding, turn off and turn on the transmitter power to check if the receiver is controlled by the connected transmitter.
